QSC SC-413C

QSC SC-413C

  • Three-way selectable, bi or tri- amplified screen channel system
  • MH-1075C provides 90° horizontal by +20° to -30° vertical coverage
  • LF-4115 is constructed of MDF and is heavily braced
  • Low-distortion waveguides provide highly articulate dialogue
  • Shallow depth (20-inch) facilitates installation
  • THX approved
Quick info
Category:

Description

Features

  • Three-way selectable, bi or tri- amplified screen channel system
  • MH-1075C provides 90° horizontal by +20° to -30° vertical coverage
  • LF-4115 is constructed of MDF and is heavily braced
  • Low-distortion waveguides provide highly articulate dialogue
  • Shallow depth (20-inch) facilitates installation
  • THX approved

Specifications

  • SPECIFICATIONS – SC-413C
  • Nominal Coverage : 90° horizontal by +20 to -30° vertical
  • Frequency Range (-6 dB) : 33–16 kHz
  • Crossover Frequency : 280 & 1700 Hz, 24 dB per octave
  • Models :

    • LF-4115
    • MH-1075C
  • Impedance :

    • LF-4115 : 4 ohms
    • MH-1075C : 8 ohms
  • Sensitivity 1 watt/1 meter, half space :

    • LF-4115 : 96.5 dB
    • MH-1075C :
      • Bi-amp : 105 dB
      • Tri-amp MF : 105 dB
      • Tri-amp HF : 107.5 dB
  • Maximum Input Power :

    • LF-4115 :
      • 400 W continuous (8h, IEC)
      • 500 W continuous (2h, AES)
      • 800 W continuous maximum
    • MH-1075C :
      • 250 W continuous passive mid-high
      • 275 W continuous
      • 80 W continuous
      • 350 W continuous
      • 800 W continuous maximum
  • Recommended Processing :

    • LF-4115 : Subsonic filter below 30 Hz, >18 dB/octave
    • MH-1075C : 4th order LR crossover at 280 & 1700 Hz via QSC processing
  • Connectors :
    Barrier strip screw terminals accept up to #10 AWG stranded wire
  • Transducers :

    • LF-4115 : 15″ woofer, 4″ copper voice coil
    • MH-1075C : 10″ midrange + 1.5″ exit, 3″ titanium diaphragm compression driver
  • Enclosure :

    • LF-4115 : Ported enclosure, tuned to 36 Hz, MDF, flared ports
    • MH-1075C : Tilt/Pan Bracket ±10° vertical & horizontal
  • Dimensions (H×W×D) inches : 30 × 18.5 × 20.3 — 30 × 39 × 20
  • Dimensions (H×W×D) mm : 470 × 762 × 516 — 990 × 762 × 508
  • Net Weight : 83 lb (38 kg) — 85 lb (39 kg)
  • System Weight : 168 lb (77 kg)
  • Baffle Cutout : 58.75″ × 32″

Downloads

QSC SC-413C Specifications
